Custom Worm and Worm Wheel Solutions

The utilization of worm and worm wheels extends across a diverse range of applications, playing a crucial role in motor reducers, lifting systems (e.g., elevators, escalators), low-speed table indexing plates in working machines, and even radars. These components demand meticulous manufacturing conditions to ensure optimal performance.

Advantages of Our Custom Worm and Worm Wheel

1. Various Ratio Design - Tailor the gear ratio to suit specific requirements.
2. Stable Operation with Low Noise - Ensure smooth and quiet functionality.
3. Simple Structure with Minimal Space Requirement - Optimize space utilization.
4. Self-locking Mechanism - Enhance security in certain applications.
5. Extensive Applications - Suitable for large transmission drive facilities, gearbox reducers, and stairlifts.

While making a worm wheel set many places to be aware such as using high-quality raw materials with no defects, manufacturing grade of datum face, tool design, and tool grades, meshing results are all very important for making a high-quality worm wheelset.

OEM Worm Wheel Manufacturers

Orris Drive, as a leading worm wheel supplier, offers customizable solutions to meet customer quantity and pricing requirements. Our customized worms & worm wheels are manufactured using precision hobbing tools, with a range of Mn/DP standard hobs available. Additionally, we can design and create bespoke hobbing tools for specialized applications. The worm undergoes different processes such as rolling cutting, general blade cutting, and plunge grinding, with a focus on utilizing high-quality rolling cutting as the primary method.

Orris Drive stands out in terms of flexibility during the testing and development phase. We provide samples, tool designs, and gear data for customer testing, ensuring a comprehensive understanding of the product's performance. This flexibility is a key advantage when choosing us as your trusted worm wheel supplier.

Types of Transmission

1. General Transmission
2. Special Transmission
3. Table Indexing Plate

Worm Wheel Design and Types

Worm wheel sets can be categorized based on appearance into cylindrical and hourglass types. According to the GB standard, the flank of the worm can be classified as ZA, ZN, ZK, and ZI. Based on raw materials, options include steel worm + bronze worm wheel (providing durability at a lower speed and cost), steel worm + plastic worm wheel (suitable for smaller systems or low-load products), and all-plastic worm and worm wheel (ideal for mini-systems and minor load products).

• Worm Wheel & Worm Materials

• Worm Wheel & Worm Manufacturing Range

• Worm Cutting： Module M0.25 ~ M12
• Worm Grinding(with robotic arm)：
• Max. Outer Diameter: 400 mm
• Max. Length: 750 mm
• Worm Wheel ：
• Max. Outer Diameter: 300 mm
• Max Module M7
